Mcintosh MP1100 Stereo Vacuum Tube Preamplifier
Fabricante:
McIntosh - (
• Ver todos os produtos da marca
McIntosh
)
Mcintosh MP1100 Stereo Vacuum Tube Preamplifier
The MP1100 Vacuum Tube Phono Preamplifier will give vinyl lovers a new level of musical enjoyment and exhilaration. It’s filled to the brim with everything you need to not only play new records or pressings from the early days of vinyl, but it will also get every last musical note and nuance out of them – including some you may have never heard before.
The MP1100 is designed first and foremost for analog audio and achieves our most accurate equalization ever. It utilizes four 12AX7A vacuum tubes, with 2 tubes used per channel in a fully balanced configuration – making it our very first fully balanced vacuum tube phono stage. For those with multiple turntables or tonearms, there are 3 sets of RCA phono inputs; XLR connectors are also available on 1 of the inputs. All phono inputs allow for adjusting both resistance (7 settings) and capacitance (8 settings). For ease of use, it comes pre-programmed with profiles for Moving Coil and Moving Magnet cartridges as well as the McIntosh MT10 and MT5 turntables. Five additional profiles are included that are fully customizable and can be assigned to any phono input. RIAA, LP, NAB, AES and 78 analog equalization curves are included.
ELECTRONIC SPECIFICATIONS
TOTAL HARMONIC DISTORTION
Phono: 0.02%
High Level: 0.005%
FREQUENCY RESPONSE
+/-0.2dB from 20Hz to 20,000Hz
+0.2, -3dB from 10Hz to 50,000Hz
MAXIMUM VOLTS OUT (BALANCED / UNBALANCED)
20/10 V RMS
INPUT IMPEDANCE
Resistance: 25, 50, 100, 200, 400, 1k or 47k Ohms
Capacitance: 50, 100, 150, 200, 250, 300, 350 or 400pF
High Level (Balanced / Unbalanced): 100k Ohms / 50k Ohms
PHONO VOLTAGE GAIN
Selectable: 40dB, 46dB, 52dB, 58dB or 64dB
SIGNAL TO NOISE RATIO
Moving Coil: 80dB
Moving Magnet: 84dB
High Level: 118dB
MAXIMUM INPUT SIGNAL (MOVING COIL)
10mV
MAXIMUM INPUT SIGNAL (MOVING MAGNET)
100mV
MAXIMUM INPUT SIGNAL (BALANCED)
20V
MAXIMUM INPUT SIGNAL (UNBALANCED)
10V
SENSITIVITY PHONO (MOVING COIL)
1.25mV
SENSITIVITY PHONO (MOVING MAGNET)
10mV
SENSITIVITY (BALANCED)
4V
SENSITIVITY (UNBALANCED)
2V
RATED OUTPUT
4V Balanced
2V Unbalanced
OUTPUT IMPEDANCE
200 Ohms Balanced
100 Ohms Unbalanced
PHONO EQUALIZATION CURVES
5: RIAA, LP, NAB, AES and 78
NOISE FILTERS
2: Rumble and Scratch
PHONO PROFILES
Pre-programmed: 4
User Programmable: 5
CONNECTIVITY
PHONO INPUT MOVING COIL
0
PHONO INPUT MOVING MAGNET
0
PHONO INPUT UNIVERSAL
3 (2 sets of RCA only inputs and 1 set of RCA or XLR inputs); each can be configured for either Moving Coil or Moving Magnet cartridges; all inputs adjustable
BALANCED LINE INPUT
1 Stereo
UNBALANCED LINE INPUT
1 Stereo
BALANCED FIXED OUTPUT
1 Stereo
UNBALANCED FIXED OUTPUT
1 Stereo
DIGITAL COAXIAL OUTPUT
1
DIGITAL OPTICAL OUTPUT
1
DIGITAL USB AUDIO OUTPUT
1
CONTROL
POWER CONTROL INPUT
1
POWER CONTROL OUTPUT
1
DIGITAL AUDIO SPECIFICATIONS
DIGITAL OUTPUT SAMPLE RATE
Optical: PCM - 24-bit/96kHz or 192kHz
Coaxial: PCM - 24-bit/96kHz or 192kHz
USB: PCM - 24-bit/96kHz or 192kHz
GENERAL SPECIFICATIONS
MULTI-CHASSIS OR SINGLE
Single
OUTPUT METERS
Yes
VACUUM TUBE OR SOLID STATE
Vacuum Tube, (4) 12AX7A
POWER CONSUMPTION (ON)
50 Watts
WEIGHTS & DIMENSIONS
DIMENSIONS (W X H X D)
17-1/2” (44.5cm) x 6” (15.2m) x 18” (45.7cm)
WEIGHT
26 lbs (11.8 kg)
SHIPPING WEIGHT
40 lbs (18.2 kg)
